JJY-12-48 4CH CCTV Power Supply
JJY-12-48 4CH CCTV Power Supply 12V, 13.5V, or 15V 4x1A
4-Channel 12V/13.5V/15V 4A Power Supply Box for Security Cameras
Power up to four security cameras with this compact and efficient power supply box, designed to provide stable and customizable voltage. An integrated switch allows you to adjust the output voltage between 12V, 13.5V, or 15V, depending on cable length or your equipment requirements.
Each channel delivers up to 1 amp, with individual protection circuits to ensure the safety of your installation. The ventilated ABS plastic housing provides good heat dissipation and easy installation.
Key Features:
Adjustable Output Voltage: 12V / 13.5V / 15V DC (switch selectable)
Total Current: 4A max (1A per channel)
Number of Outputs: 4 independently protected channels
Housing: Lightweight and durable ABS plastic with ventilation
Safety: Overvoltage, overload, and short-circuit protection
Installation: Wall mounting, accessible screw terminals
Compatibility: Analog, AHD, CVI, TVI, and IP cameras, 12V DC
Ideal for small-scale CCTV installations, this power supply offers performance, reliability, and flexibility in a compact form factor.
Technical specifications
| Type | power unit |
| Number of outputs | 4 exits |
| Nominal voltage | 12–15V |
| Output current | 4 * 1A |
| Additional features | Output voltage switching |
| Body material | Plastic |
